Stelux CG Metallic Media
Stelux CG is a non-ferrous metallic abrasive media used for deburring, deflashing, surface cleaning, finishing, and controlled blasting applications. Its softer impact compared with steel abrasives makes it suitable for aluminum, zinc die castings, non-ferrous components, and parts requiring a clean surface finish.
Product Overview
Stelux CG is produced as an angular stainless steel abrasive for applications requiring stronger cutting performance than rounded stainless steel shot. Its angular particles support effective removal of scale, oxide, coating, and surface contaminants while maintaining the benefits of stainless media.
The product is suitable for stainless steel fabrication, aluminum products, die casting, surface roughening, coating preparation, and industrial finishing processes that require clean and contamination-controlled blasting results.
Main Advantages
Strong Cutting Action
Angular particles provide effective cleaning, roughening, and surface preparation.
Rust-Free Blasting
Helps prevent ferrous contamination on stainless steel and non-ferrous materials.
High Hardness
Average hardness of 58 ± 3 HRC supports aggressive and durable blasting performance.
Clean Surface Profile
Suitable for coating preparation and controlled surface roughening applications.
Technical Data
Specification
| Product Name | Stelux CG |
| Media Type | Stainless steel angular abrasive media |
| Chemical Composition |
Carbon (C): ~2% Chromium (Cr): ~30% Silicon (Si): ~3.5% Manganese (Mn): ~2% |
| Size |
From 120 to 10 Mesh 0.125 mm to 2 mm |
| Average Hardness | 58 ± 3 HRC (650 HV) |
| Specific Gravity | ≥ 7.0 |
| Shape | Angular |
| Microstructure | Austenitic matrix with martensitic islands and chromium carbides |
| Packaging |
Bags
1000 kg box - 50 bags of 20 kg (44 lb)
500 kg box - 25 bags of 20 kg (44 lb) Customized packing upon request. |
Stelux CG - Cumulative Size Distribution (%)
| Mesh # |
Sieve Size (mm) |
STELUX CG 200 |
STELUX CG 150 |
STELUX CG 100 |
STELUX CG 60 |
STELUX CG 50 |
STELUX CG 40 |
STELUX CG 30 |
STELUX CG 20 |
STELUX CG 10 |
|---|---|---|---|---|---|---|---|---|---|---|
| 7 | 2.80 | AP | ||||||||
| 8 | 2.36 | Max 10 | AP | |||||||
| 10 | 2.00 | Max 10 | AP | |||||||
| 12 | 1.70 | Max 10 | ||||||||
| 14 | 1.40 | Min 85 | AP | |||||||
| 16 | 1.18 | Min 85 | Max 10 | |||||||
| 18 | 1.00 | Min 85 | Max 10 | |||||||
| 20 | 0.85 | AP | ||||||||
| 25 | 0.71 | Min 85 | ||||||||
| 30 | 0.60 | Min 85 | ||||||||
| 35 | 0.50 | |||||||||
| 40 | 0.425 | Min 85 | ||||||||
| 45 | 0.355 | AP | ||||||||
| 50 | 0.300 | AP | ||||||||
| 80 | 0.180 | Min 85 | ||||||||
| 120 | 0.125 | Min 85 | ||||||||
| 200 | 0.075 | Min 85 |
Applications
Recommended Usage
- ✓ Rust-free abrasive blasting
- ✓ Surface roughening and profiling
- ✓ Coating preparation
- ✓ Oxide and scale removal
- ✓ Stainless steel cleaning and finishing
- ✓ Stainless steel fabrication
- ✓ Aluminum and non-ferrous products
- ✓ Die casting components
- ✓ Decorative metal surfaces
- ✓ Industrial surface treatment operations
